RAGE antibody detects RAGE protein in rat lung by immunohistochemical analysis.
Sample: Paraffin-embedded rat lung.
RAGE antibody (GTX23611) diluted at 1:400.

Antigen Retrieval: Citrate buffer, pH 6.0, 15 min

Rat tissue extract (50 μg) was separated by 10% SDS-PAGE, and the membrane was blotted with RAGE antibody (GTX23611) diluted at 1:5000. The HRP-conjugated anti-rabbit IgG antibody (GTX213110-01) was used to detect the primary antibody.

Mouse tissue extract (50 μg) was separated by 12% SDS-PAGE, and the membrane was blotted with RAGE antibody (GTX23611) diluted at 1:5000. The HRP-conjugated anti-rabbit IgG antibody (GTX213110-01) was used to detect the primary antibody.

IHC-P analysis of normal mouse kidney tissue with (ledt) or without (right) RAGE antibody at a dilution of 1:20. Heat induced antigen retrieval was performed using 10mM sodium citrate (pH6.0) buffer, microwaved for 8-15 minutes.
Antigen Retrieval: Trilogy™ (EDTA based, pH 8.0) buffer, 15min

IHC-P analysis of normal mouse heart tissue with (ledt) or without (right) RAGE antibody at a dilution of 1:20. Heat induced antigen retrieval was performed using 10mM sodium citrate (pH6.0) buffer, microwaved for 8-15 minutes.
Antigen Retrieval: Trilogy™ (EDTA based, pH 8.0) buffer, 15min

IHC-P analysis of normal mouse lymph node tissue with (ledt) or without (right) RAGE antibody at a dilution of 1:20. Heat induced antigen retrieval was performed using 10mM sodium citrate (pH6.0) buffer, microwaved for 8-15 minutes.
Antigen Retrieval: Trilogy™ (EDTA based, pH 8.0) buffer, 15min

The data was published in the journal Sci Rep in 2016. PMID: 26739898

The data was published in the journal Oncotarget in 2016.PMID: 27121132

The data was published in the journal PeerJ in 2018. PMID: 29888131
